Dry Copper Wire Recycling Machine 50-1000 kg/h Capacity

Name: Dry Copper Wire Recycling Machine 501000 kgh Capacity
Brand: Xrido
Price: 18 USD

Wholesale Dry Copper Wire Recycling Machine 50-1000 kg/h Capacity from china suppliers

Brand Name : Xrido

Model Number : Customizable

Certification : CE ISO TUV

Price : CN¥18,650.24/sets 1-9 sets

Payment Terms : L/C,D/A,D/P,T/T,Western Union,MoneyGram,Negotiable

place of origin : China

video outgoing-inspection : Provided

machinery test report : Provided

core components : PLC, Engine, Bearing, Gearbox, motor, Pressure vessel, Gear

warranty : 1 Year

material / metal processed : Stainless Steel, Brass / Copper, Alloy, Carbon Steel, Aluminum

power (kw) : 5

weight (kg) : 500

key selling points : Multifunctional

Product name : Dry Copper Wire Recycling Machine

Capacity : 50-1000 kg/h

Type : metal recycling/scrap recycling

Advantage : Easy Operation High Efficiency

Feeding size : Customized

Input Materials : Copper Cable Aluminum Wires

Final product : Customized particle

Application : bicycle circuit lines, communication cables

After-sales Service Provided : Video Technical Support

Condition : New

Marketing Type : Ordinary Product

Warranty of core components : 1 Year

Showroom Location : None

Applicable Industries : Building Material Shops, Machinery Repair Shops, Construction works , Other

Contact Now

Automatic Cable Granulator Copper Shredder Small Waste Cable Scrap Copper Wire Recycling Mini Copper Wire Granulator

Products Description

Copper Wire Recycling Machine/Copper Rice Machine

Small waste copper wire recycling machine, also known as copper rice machine or waste wire and cable processing equipment, is mainly used for the recycling and processing of waste wires and cables. Dry copper recycling machine is a professional production line for dry separation of waste wire and cable. For example, circuit lines, communication cables, and wire strippers are not suitable for processing (various civilian wires) waste material's thin filaments, etc.

Dry Copper Wire Recycling Machine 50-1000 kg/h Capacity

Working principle of small waste copper wire recycling machine:
The small waste copper wire recycling machine separates the copper and plastic in the waste wires and cables through a series of crushing and sorting processes. Specifically, the waste wires and cables are first crushed by the crusher, and then separated by the airflow specific gravity separator, and finally pure copper rice and plastic particles are obtained.

Features and advantages of small waste copper wire recycling machine:
1. Efficient separation: The small waste copper wire recycling machine adopts advanced crushing and sorting technology, which can efficiently separate the copper and plastic in the waste wires and cables, with high separation efficiency, and the separated copper rice and plastic particles are of high purity.
2. Energy saving and environmental protection: This type of equipment generates less noise and dust during operation, and meets national environmental protection standards. At the same time, by recycling copper and plastic in waste wires and cables, the exploitation and consumption of natural resources can be reduced, which is conducive to environmental protection and sustainable development.
3. Easy to operate: Small-scale waste copper wire recycling machines usually adopt a fully automated operation mode, and only one person is needed to complete the entire recycling process. At the same time, the equipment is also intelligent and automated, and can automatically detect the operating stability to ensure the normal operation of the equipment.
4. Small investment: Compared with large-scale waste copper wire recycling equipment, small-scale waste copper wire recycling machines have lower prices and relatively small investment costs, which are suitable for small-scale waste wire and cable recycling business.

Model	Diameter of materials	Capacity(kgs / hr)	Power(KW)	Dimension(LWH)	Weight(kg)
Aite-150	φ0.5-20	100-300	5	560 * 805 * 1550	500
Aite-400	φ0.5-20	300-400	15	1800 * 1300 * 1700	2850
Aite-600	φ0.5-20	500-600	37	2800 * 1800 * 2100	4200
Aite-800	φ0.5-20	700-800	45	2800 * 2000 * 2100	6500
Aite-1000	φ0.5-20	800-1000	55	2800 * 2500 * 2100	7800

Working Principle Of Copper Wire Recycling Machine

Dry copper rice machine (waste wire and cable processing equipment):

The shredder is used to crush the material into a length of about 3 cm, and then sheared and crushed by a secondary crusher, and then sorted by high-precision airflow sorting to obtain plastic.

And copper, undivided plastics are sorted by electrostatic separators to ensure copper reuse.

1,After the waste wire and cable crushing process,full-automatic mechanical separation can completely separate copper and plastic,and achieve the purpose of comprehensive utilization, with high economic benefits. And no dust and no secondary pollution.
2,In addition, the device is an overall modular structure,easy to install and debug, and transport (customers can be produced after the power supply is purchased),stable performance.

Application scope
Small-scale waste copper wire recycling machines are mainly suitable for homes, small-scale waste wire and cable recycling stations and other places, and can process waste communication wires, automotive wires, computer wires, telephone wires, household appliance wires and other oil-free wires.

Mainly used in automobile electric line, communication cable line, waste wire, telephone line, decoration wire, computer wire, etc. Copper cable granulator is suitable for processing all kinds of scrap wires and cables, wire and cable with a diameter of 1-200 mm, such as Automobile electrical wire, car electric wire, motorcycle electric wire, power cable, communication cable, signal cables and other miscellaneous cables which cannot be processed by wire stripping machine.

Successful Project

Company Profile

Dry Copper Wire Recycling Machine 50-1000 kg/h Capacity

Henan Xrido Environmental Protection Technology Co.Ltd.is a high-tech enterprise committed to the R &D, manufacturing and sales of mechanical equipment in the environmental protection and recycling industry. We mainly focuses on design and manufacturing automatic waste segregation machine garbage sorter construction waste sorting equipment. include trammel screen machine, air separation machine, magnetic separators, garbage bag breaking machine, waste shredder machine, manual sorting tables, waste baling machine, chain plate feeder, belt conveyor.etc.

Our machine has passed ISO9001:2000, CCC,CE certification.Our machines has already spread over the world.We can provide customers with one-stop service and solutions, complete equipment, on-site installation, and after-sales support.
